Topology

Configure Nexus1

feature interface-vlan
feature lacp
feature vpc

vpc domain 1
peer-switch
peer-keep alive destination 1.1.1.2 source 1.1.1.1 vrf default !Note VRF important
exit

vlan 10

interface vlan 1
description VPC-KEEPALIVE
no shut
ip add 1.1.1.1/30

interface vlan 10
description DATA_VLAN
no shut
ip add 10.1.1.1/24

int port-channel 10
description VPC-PEER
switchport mode trunk
vpc peer-link

int port-channel 20
description DATA_VLAN
switch port mode trunk
vpc 20

interface eth1/1
channel-group 10
interface eth1/2
channel-group 10

int eth1/4
channel-group 20

Configure Nexus2

feature interface-vlan
feature lacp
feature vpc

vpc domain 1
peer-switch
peer-keep alive destination 1.1.1.1 source 1.1.1.2 vrf default !Note VRF important
exit

vlan 10

interface vlan 1
description VPC-KEEPALIVE
no shut
ip add 1.1.1.2/30

interface vlan 10
description DATA_VLAN
no shut
ip add 10.1.1.2/24

int port-channel 10
description VPC-PEER
switchport mode trunk
vpc peer-link

int port-channel 20
description DATA_VLAN
switch port mode trunk
vpc 20

interface eth1/1
channel-group 10
interface eth1/2
channel-group 10

int eth1/4
channel-group 20

Configure Router 37254

vlan database
vlan 10
exit

enable
configure t
int vlan 10
ip add 10.1.1.10 255.255.255.0

int port 1
switchport trunk encap dot1q
switchport mode trunk

int fa1/0
channel-group 1 mode on
int fa1/1
channel-group 1 mode on
